HIGH SPEED ROLLING DOOR

TOP

CALL

THINGS TO KNOW ABOUT HIGH-SPEED ROLLING DOORS

High-speed automatic roll-up doors are types of doors used for industrial business purposes. With fast opening and closing speeds, they are convenient, safe, and create a good working environment in factories.

ROLLASKA

ROLLWAY

ROLLWAY DOUBLE

EXPLORE THE BENEFITS OF HIGH-SPEED ROLLING DOORS

In AUTO mode, the opening height (OH) can be set to the desired height (optional)

All parts pass internal testing

With protective structure to prevent and reduce dust and moisture accumulation inside.

ROLLWAY

High speed rolling door is a type of door used in industry. Very simple and safe for industrial environments with fast opening and closing speed.

Outstanding advantages

Reduce heat loss, increase air conditioning efficiency Improve working environment, prevent dust, insects or birds Reduce noise and air pollution with quick open/close function Prevent workplace from sudden heavy rain.

Airtight design

Rollaska is specially designed to prevent wind from entering from outside with tightness in each part, no gaps in the upper frame.

PRODUCT SPECIFICATIONS

PRODUCT

HIGH SPEED ROLLING DOOR

CODE

RWTH-M4-1E, 2E, RWTH-M4-Airtight  

TECHNICAL SPECIFICATIONS

Heat resistance

Ambient temperature: 25 C ~ 0 C

Hot room temperature: 70 C MAX

Cold room temperature: 0 C MIN

Engine

Gear motor using brake

Available 380V / 50 Hz 3 phase

Curtain

Polyester – PVC Coated Sheet

Thickness 0.5 + 0.2 mm

Color: Ivory, Green, Blue, Orange, Gray, Transparent.

FEATURES AND DIMENSIONS

Width x height

MIN OW 1,600 x OH 1,200 mm.

MAX 8,000 x 5,100 mm

Special large size always meets

Curtain features

GLOSSY SURFACE

Transparent window

PRODUCT SPECIFICATIONS

PRODUCT

HIGH SPEED ROLLING DOOR

CODE

RWTH-M4-1E, 2E, RWTH-M4-Airtight

SPECIFICATIONS

Heat resistance

Ambient temperature: 25 C ~ 0 C

Hot room temperature: 70 C MAX

Cold room temperature: 0 C MIN

Engine

Gear motor using brake

Available 380V / 50 Hz 3 phase

Curtain

Polyester – PVC Coated Sheet

Thickness 0.5 + 0.2 mm

Color: Ivory, Green, Blue, Orange, Gray, Transparent.

FEATURES AND DIMENSIONS

Width x height

MIN OW 1,600 x OH 1,200 mm.

MAX 8,000 x 5,100 mm

Kích thước lớn đặc biệt luôn đáp ứng

Curtain features

GLOSSY SURFACE

Transparent window

SPECIFICATIONS

Model

Parameters 1E, 2E

RWTH-M4-1E, 2E

AIRTIGHT Parameters

RWTH-M4-1E, 2E

Open/Close Speed

0.7 ~ 0.9 m/sec  

Engine

Gear motor with brake 0.4 ~ 1.5 Kw

Power supply voltage

3 phase 380V+N (Special order for other voltages is preferred)

Door opening width (OW)

1.6m ~ 8.0 m  

Door opening height (OH)

1.2 m ~ 5.1 m  

Safety sensor

Quang điện SW 2-Pha  

Control box

450 mm x 270 mm x170 mm (Cao x Rộng x Sâu)   

Heat resistance

0 ~ 70 C  

Air leak
(volume)

Positive pressure

Negative pressure

16.1 (m3/h ·m2)

9.3 (m3/h ·m2)

SPECIFICATIONS

Parameters 1E, 2E

MODEL

RWTH-M4-1E, 2E

RWTH-M4-AIRTIGHT

Open/Close Speed

0.7 ~ 0.9 m/sec

Engine

Gear motor with brake 0.4 ~ 1.5 Kw

Power supply voltage

3phase 380V+N (Special order for other voltages is preferred)

Door opening width (OW)

1.6m ~ 8.0 m

Door opening height (OH)

1.2 m ~ 5.1 m

Safety sensor

2-Phase SW Photovoltaic

Control box

450 mm x 270 mm x170 mm (Cao x Rộng x Sâu)

Heat resistance

0 ~ 70 độ C

Leakage (volume)

Positive pressure

16.1 (m3/h ·m2)

31.1 (m3/h ·m2)

Negative pressure

9.3 (m3/h ·m2)

11.5 (m3/h ·m2)

STANDARD

OPTIONS

PVC color

Fiber type

PVC mesh

Frame color

*The frame is made of powder coated steel plates with high corrosion resistance.

Options

Stainless steel

STANDARD

PVC color

OPTIONS

Fiber type

Lưới PVC

Frame color

*The frame is made of powder coated steel plates with high corrosion resistance.

Options

Stainless steel

POWER CONSUMPTION OF ROLLWAY MOTOR

Motor (kW)

0.4  

0.75

1.5

Breaker (A.)

1-1.6

1.6-2.5

2.5-4

Current (A.)

1.8

3.3

AUTOMATIC MODE

ROLLFREEZER

ROLLFREEZER high-speed door is the first in the industry to solve the problem of self-frosting. The freezer with patented double curtain structure technology, effectively prevents air leakage.

Two-layer structure

By bringing the temperature of the middle and outer panels closer to the inside temperature, the high-speed rolling door can minimize the temperature difference between the inside and outside, thereby preventing air flow outside ingress. This reduces the risk of condensation and heat loss through the joints.

Humidity and temperature control function

The temperature sensor in the high-speed rolling door will activate the heating function, helping to regulate the internal temperature, preventing the temperature difference between the inside and the outside. This function helps maintain a stable temperature and respond quickly to environmental changes.

Measures to prevent condensation

High speed rolling door is equipped with an internal fan that blows air to prevent condensation on the internal surface. If any condensation occurs, the internal heating plate will evaporate the water and release it outside, preventing water from dripping down.

Three-layer structure

High-speed rolling doors are equipped with highly insulated aluminum panels and inner plastic panels, along with a heat-retaining layer underneath, which helps to minimize heat transfer through the panels.

SPECIFICATIONS

Double

RW-F

RW-L

Open/close speed

Specific details

Engine

Engine brake

0.2kw ~ 1.5kw

3 pha AC 200V

Power supply

3 pha AC 200V

Door Width

1.6m ~ 4.0m

Door height

1.2m ~ 4.2m

Regulatory mechanism

Automatically stops when reaching the set height

Safety sensor

2 pairs of photoelectric sensors

Control box

Installable vertical steel box (insulated material)

Vertical steel box
can be installed

Installable vertical steel box (insulated material)

Size

Height 450mm, depth 170mm

Conversion

Manual / Automatic

THÔNG SỐ KỸ THUẬT

Thông số 1E, 2E

MODEL

RWTH-M4-1E, 2E

RWTH-M4-AIRTIGHT

Tốc độ Đóng/Mở

0.7 ~ 0.9 m/sec

Động cơ

Động cơ bánh răng kèm thắng 0.4 ~ 1.5 Kw

Điện áp nguồn

3phase 380V+N (Ưu tiên hàng đặc biệt cho điện áp khác)

Chiều rộng mở cửa (OW)

1.6m ~ 8.0 m

Chiều cao mở cửa (OH)

1.2 m ~ 5.1 m

Cảm biến an toàn

Quang điện SW 2-Pha

Hộp điều khiển

450 mm x 270 mm x170 mm (Cao x Rộng x Sâu)

Khả năng chịu nhiệt

0 ~ 70 độ C

Rò rỉ (thể tích)

Áp suất dương

16.1 (m3/h ·m2)

31.1 (m3/h ·m2)

Áp suất âm

9.3 (m3/h ·m2)

11.5 (m3/h ·m2)

MATERIALS AND COLORS

FRAME

Rollway - Double

EXTERIOR: Blue polyurethane panel

INSIDE:
Blue polyurethane
panel

ANTI-CONDENSATION PANELS: Gray

Rollway - F

Blue polyurethane sheet

Rollway - L

Blue polyurethane sheet

HEAT INSULATION: Black

ALUMINUM PROTECTION PLATE: Silver

Frame color

The frame is made of galvanized steel sheet with high corrosion resistance.

MATERIALS AND COLORS

Rollway - Double

EXTERIOR: Blue polyurethane panel

INSIDE: Blue polyurethane panel

ANTI-CONDENSATION PANELS: Gray

Rollway - F

Blue polyurethane sheet

Rollway - L

Blue polyurethane sheet

HEAT INSULATION: Black

ALUMINUM PROTECTION PLATE: Silver

FRAME

Frame color

The frame is made of galvanized steel sheet with high corrosion resistance.

TEST RESULTS TABLE

Temperature
[°C]

Humidity
[%]

Water vapor
[g/m³]

Condensate [g/m³]

Outside air

41.5

Outer surface of curtain

39.6

Inside surface of curtain

39.1

Outer surface of curtain

Inside surface of curtain

-11.5

Surface of the cold control panel

-14.8

NOTE

The test was performed on December 26, 2023, under the conditions of an outside air temperature of 41.5°C and a humidity of 66.7%.

The temperature difference between inside and outside was measured using temperature and humidity sensors, and the results showed no condensation.
